Precision. Performance. Craftsmanship.
Outline Specifications
Frers Naval Architecture
Nautors Swan 80 Flush Deck
25.08m Performance Cruiser
Delivered in 2013
Principal Dimensions
Length Overall
Length of Waterline
Beam
Draft
Displacement
Ballast
22.19m/72.80ft
25.08m/82.28ft
6.08m/19.95ft
3.30m/10.80ft
36,200kg/79,850lbs
14,200kg/31,300lbs
Machinery & Tankage
Engine
Fuel Capacity
Water Capacity
Electrical System
Generators
Max Speed
Range
Steyr MO196 Diesel (140kW / 190Hp)
1,500L/396 gallons
1,200L/317 gallons
DC 24V/AC 230V
xx
10.0 kn
1400.0nm at 8.5kn
Sail Plan & Rigging
Mast
Boom
Rigging
Furling
Sails
Main Areas
Blade Area
Jib
Asymmetric Spinnaker
High-Modulus Hall Spars Carbon Fiber
34-700 Standard Modulus V-Boom
Hybrid PBO and Carbon Standing Rigging
Reckmann UD-4s hydraulic with S4.5 dble groove carbon foils
xsqm
xsqm
xsqm
xsqm
xsqm
Racing:
3Di Full Batten Mainsail with 3 reefs (2013)
Furling 3Di 104% Jib (2013)
Furling 3Di 90% Short Hoist #4 Jib (2013)
Racing A2 Asymmetric Spinnaker (2013)
Racing A3 Asymmetric Spinnaker (2015)
Cruising:
Hank On 3Di Genoa Staysail (2013)
Furling Cruising Gennaker (2013)
Furling Code Zero on Furler (2015)
Furling Spinnaker Staysail (2013)
Trisail (2013)
General Arrangement
Guests
Crew
Tenders
3 Cabins/8 Guests
1 Cabin/ 3 Crew
1x 3.3m Zodiac RIB
Design & Construction
Construction
Classification
Naval Architecture
Exterior Design
Interior Design
Builder/Year
Frers Naval Architecture
Germanischer Lloyds 100 A5 Sailing Yacht
Carbon Fibre SPRINT / Pre-Preg Corecell Sandwich Laminate
Nautor Swan - Misa Poggi
German Frers - Lucio Micheletti
x/2013
